CC10-2412DF-E|TDK-Lambda power supply

CC10-2412DF-E|TDK-Lambda Power Supply Manufacturer: TDKLambda Product Category: DC/DC Converter - Through Hole REACH - SVHC: Brand: TDK-Lambda Height: 8.5 mm (.335 in) Industrial: Industrial Input Voltage: 18 V to 36 V Input Voltage - Max: 36 V Voltage - Min: 18 V Input Voltage (Nominal): 24 V Insulation: Isolated Insulation Voltage: 50 V Length: 35.6 mm (1.402 in) Max Operating Temperature:   85 C Min Operating Temperature: - 0 C Mounting Style: Through Hole Number of Outputs: 2 Output Output Current—Channel 1: 450 mA Output Current— 2: 450 mA Output Power: 10 W Output Voltage—Channel 1: 12 V Output Voltage—Channel2: - 12 V Product Type: Isolated DC-DC Converters Series: CC10 Subcategory: DC-DC Converters : 22.6 mm (0.89 in) Part Number Alias: CC10-2412DF-E|TDK Power|TD-Lambda Power Unit Weight: 10 g TDK-Lambda CC Series DC-DC Converter CC10-2412DF-E|TD Power|TDK-Lambda Power TDK-Lambda CC Series DC-DC Converters offer high-density output voltages of 3.3V, 5V 12V and 15Vdc with rated output power from 3W to 30W. The CC10-2412DF-ETDK Power|TDK-Lambda Power CC modules are available in through hole or SMD packages, with or without shielded metal cases. They are suitable for applications with temperature range from -40°C to  85°C and can be efficiently fully regulated (typical 92%). TDK-Lambda CC Series DCDC Converters are ultra-compact, fully isolated converters with a wide range of DC inputs (nominal 24V or 48V), making ideal for telecom, test, industrial and broadcast applications. Features Small footprint, compact size Through hole or SMD versions 5V, 12V,24V and 48V input 3.3 to 30V single output, ±12 to ±15V dual output Output voltage regulation to output isolation RoHS compliant 5 year warranty Stand-alone Multiple input voltage configurations Applications Industrial Test Communication Broad

TDK power supply|TDK-Lambda agent|TDK-Lambda programmable power supply|TDK-Lambda programmable power supply|GENESYS programmable power supply|Lambda power supply
