CC1R5-2405SF-E |TDK-Lambda| Isolated DCDC Converter

CC1R5-2405SF-E TDK-Lambda Isolated DCDC Converter, 18 →36 V DC Input, 5V DC Output, 1.5W, CC-E Series Brand TDK-Lambda Output Voltage 5V Input Voltage Range 18 → 36 V DC Rated Power 1.5W Input Voltage Rated Value 24 V DC Current 300mA Mounting Type Through Hole Isolated Yes Number of Outputs 1 Output Voltage Adjustment Range 4.5 → 6V Package DIP Isolation Voltage 500V AC Width 16.6mm Depth 8.5mm 16.51mm Series CC-E Load Regulation 40mV Compliance Standards CE, cULus, EN 6950-1, NEMKO, UL/CSA 60950-1 Lowest Temperature -40°C Efficiency 7% Highest Temperature 85°C CC-E Series, 1 W to 12 W Single/Dual Output The CC-E Series a wide range of field-proven products to fit a variety of applications. These converters come in 68 different input voltage and output power combinations. They are lightweight, a metal case to reduce radiated EMI. Typical applications for this series include test and measurement, broadcasting, process control, and general industry. Features and Advantages Independent • Compact • Multiple input voltage configurations • Open frame (no potting) • Uses less printed circuit board area • No external components needed •pler system configuration • Lighter weight, suitable for surface mounting (R type)
