CUS200M-12/A TDK power supply - chassis mount AC-DC, Medical, 115-230V, Output 12V 16.7A, 200W cov

TDK-Lambda has developed the ultra-thin, high efficiency, fan-less CUS200M series, in which the CUS200M is 6% efficient and 32% smaller than the previous generation (150W HWS150/ME). The CUS200M is a super-thin high-efficiency medical power supply with a wide voltage input range. ■ Main Features Compact size: 3’’ x 5’’ x 1.3’’ (762 x127 x 34mm) High efficiency: up to 94% High power density: up to 10.3W/inch3 Natural: 200W, forced air cooling: 250W Output models: 12V, 18V, 24V, 4V Built-in: 5V 0.6A (1A forced air cooling) auxiliary power, DC OK, Remote on/off remote control switch Wide operating temperature range -20°C ~  70°C Safety Approval: EN/UL60950-1, IEC60601 2nd 3rd edition (2 x MOPPs) Altitude: 4000m Medical applications, 5000m ITE applications 3 year warranty■ Product Applications Medical equipment Broadcast and professional audio Test and measurement TDK-Lambda CUS200M series Specifications as follows: CUS20M-12 CUS200M-12/A CUS200M-18 CUS200M-18/ CUS200M-24 CUS200M-24/A CUS200M-36 CUS20M-36/A CUS200M-48 CUS200M-48/A
