ICM-20948 is a high-performance 9-axis inertial measurement unit (IMU), claimed to be the world's lowest power 9-axis motion tracking device, produced by InvenSense company. Very suitable for smartphones, tablets, wearable sensors, and IoT applications, widely used in mobile devices, robots, drones, and various occasions that require precise posture measurement and motion tracking.

Adopting a 3-axis gyroscope, 3-axis accelerometer, 3-axis geomagnetic sensor, and digital motion processor (DMP) packaged in a 3mm x 3mm x 1mm (24 pin QFN) package ™）

DMP unloads motion processing algorithm calculations from the main processor to improve system power performance

The software driver program fully complies with Google's latest Android version

Support EIS FSYNC

ICM-20948 supports auxiliary I2C interface for external sensors, on-chip 16 bit ADC, programmable digital filters, embedded temperature sensors, and programmable interrupts.

The working voltage range of ICM-20948 is as low as 1.71V. The communication ports include I2C and 7 MHz high-speed SPI.

ICM-20948 is a high-performance 9-axis inertial measurement unit (IMU), claimed to be the world's lowest power 9-axis motion tracking device, produced by InvenSense company. Very suitable for smartphones, tablets, wearable sensors, and IoT applications, widely used in mobile devices, robots, drones, and various occasions that require precise posture measurement and motion tracking.

Adopting a 3-axis gyroscope, 3-axis accelerometer, 3-axis geomagnetic sensor, and digital motion processor (DMP) packaged in a 3mm x 3mm x 1mm (24 pin QFN) package ™）

DMP unloads motion processing algorithm calculations from the main processor to improve system power performance

The software driver program fully complies with Google's latest Android version

Support EIS FSYNC

ICM-20948 supports auxiliary I2C interface for external sensors, on-chip 16 bit ADC, programmable digital filters, embedded temperature sensors, and programmable interrupts.

The working voltage range of ICM-20948 is as low as 1.71V. The communication ports include I2C and 7 MHz high-speed SPI.

5. Characteristics (Product Features)

The lowest power 9-axis device with a power of 2.5 mW

FSR programmable three-axis gyroscope with ± 250 dps, ± 500 dps, ± 1000 dps, and ± 2000 dps

FSR programmable three-axis accelerometers with ± 2g, ± 4g, ± 8g, and ± 16g

Triaxial geomagnetic field with a range of ± 4900 µ T

Onboard Digital Motion Processor (DMP)

Support Android

Supporting auxiliary I2C interface for external sensors

On chip 16 bit ADC and programmable filter

7 MHz SPI or 400 kHz fast mode I ² C

Digital output temperature sensor

The working range of VDD is 1.71V to 3.6V

MEMS structures for chip level sealing and bonding

Compliant with RoHS and green standards

6. Application Fields

Smartphones and tablets

Sensors for wearable devices

IoT (Internet of Things) applications
