ST VN7016AJEPTR, AEC-Q100 Qualified Automotive Single-Channel Smart High-Side Power Switch

Voltage Specifications

Operating voltage: 4V ~ 28V (for 12V automotive battery systems)Maximum transient withstand voltage: 40V (compliant with automotive load-dump surge requirements)

Turn-on Characteristics

Typical on-resistance Rds(on): 16 mΩ (low temperature rise under high current)Typical current limit threshold: 77A

Power Consumption

Maximum standby current: 0.5 μA (ultra-low quiescent power)

Control Interface

Control signal compatible with 3.3V / 5V CMOS MCUs; can be driven directly by IO pins

Core Applications: 12V Passenger Vehicle Body Electronics

• Automotive headlight systemsDriver for LED headlights and halogen headlights

• Load channels for BCM (Body Control Module)

• Fog lights, turn signal lamps, Daytime Running Lights (DRL)

• Electric water pumps, fans, solenoid valves (inductive loads)

• Seat motors, trunk actuators; replacement for various automotive relays

• Power distribution modules for 12V electronic control units in construction machinery
