ST L99PM62GXPTR, AEC-Q100 Automotive Highly-Integrated System Basis IC / PMIC Power Management & Driver IC

Power Supply

Battery input voltage: 5.5V ~ 18V (12V automotive battery system)Ultra-low standby power consumption, supports local/remote wake-up; typical quiescent current: 6mA

Two integrated 5V LDO regulatorsOne for MCU core power supply, the other for sensor peripheralsNo electrolytic capacitors required at outputs, simplifying external BOM

Communication Transceivers (Vehicle Network)

✅ HS-CAN: Compliant with ISO11898-2/5, supports Partial Networking wake-upLIN 2.1 LIN transceiver (compatible with SAE J2602)

Application Scope (Industries & Specific Products)

Primary Application: 12V passenger vehicle body electronics (core target)

• Door Zone ECUWindow lifting, mirror adjustment, door lock and door light control (native target application of this IC)

• BCM (Body Control Module)

• Seat control unit, trunk controller

• Light control module, exterior light actuators

• Compact intelligent automotive actuators, LIN/CAN distributed nodes

❗Application LimitationOnly applicable to 12V gasoline / hybrid passenger vehicles. Not suitable for 24V commercial vehicles or 400V new energy high-voltage systems.
