TDK-Lambda HWS3000G-48 3000W Programmable AC-DC Power Supply

TDK-Lambda HWS3000G-48 3000W Programmable AC-DC Power Supply


. Official Name

TDK-Lambda HWS3000G-48

Full Name: 3000W Programmable AC-DC Power Supply (Single-phase Input, 48V Output)

Common Name: Industrial-grade 3kW 48V Programmable Power Supply / High-power Programmable DC Power Supply

2. Core Functions

It is a high-power power supply that converts alternating current into stable direct current with adjustable voltage and current.

  • Power Supply: Converts 85–265VAC mains electricity into 48V/62.6A/3000W DC power to supply stable high-power DC power for equipment.

  • Programmable Function: Continuously adjustable voltage (38.4–52.8V) and current (0–62.6A) with CV/CC constant voltage & constant current mode; supports RS485 (Modbus) and analog signal control.

  • Capacity Expansion: Up to 10 units in parallel and 3 units in series to meet higher voltage and current requirements.

  • Protection Functions: Over-voltage, over-current, over-temperature and short-circuit protection, with remote on/off control.

3. Application Scope

Mainly applied in high-reliability and high-power fields such as industry, semiconductor and test & measurement:

  • Semiconductor Equipment: Power supply for wafer processing, photolithography and etching machines.

  • Laser Processing: Power supply for laser cutting, welding and marking machines.

  • RF & Communication: Power supply for RF amplifiers, base stations and testing instruments.

  • Industrial Automation: Large servos, robots and production line equipment.

  • Test & Measurement: Battery testing, electronic load and aging test systems.

  • Others: Medical equipment (certification required), charging piles and auxiliary power supplies for energy storage systems.

4. Key Parameters Overview

  • Input: 85–265VAC (Single-phase)

  • Output: 48V (adjustable) / 62.6A / 3000W

  • Efficiency: 92% (Typical)

  • Dimension: 269×150×61mm

  • Features: Programmable, parallel/series connection supported, high isolation, wide temperature operation
