Murata MYMGK1R820GRSR-H Non-Isolated Point-of-Load DC-DC Power Converter Module

Function

Input voltage: 4.5–5.5V (typical 5V), adjustable output voltage: 0.7–1.8V, maximum output current up to 20A. It provides low-voltage, high-current and high-precision local power supply for core chips such as FPGA, CPU and ASIC.

Integrated with inductor, MOSFET, control IC and compensation circuits, it adopts mono-block structure without complicated peripheral components, which simplifies power circuit layout and saves PCB space.

It features high efficiency, low noise and excellent heat dissipation performance. It supports remote on/off control and remote sense function with fast load transient response, avoiding crash and malfunction of core chips caused by voltage fluctuation.

Operating temperature range covers -40℃ to +105℃ for industrial grade, ensuring stable power supply under high temperature and suitable for long-term continuous operation equipment.

Application Scope

Communication Equipment: Core power supply for FPGA and CPU in 5G micro base stations, optical transmission equipment, network switches, routers and servers.

Industrial Control: High-current low-voltage power supply for industrial mainboards, motion control boards, machine vision systems and embedded industrial controllers.

Data Center: Power supply for high-density servers, storage devices, AI accelerator cards and GPU/FPGA computing boards.

High-end Consumer Electronics: Power supply for core processors of high-performance laptops, tablets, AR and VR devices.

Medical Equipment: Applied to imaging devices, monitors and other scenarios requiring strict power noise and stability performance.

Electrical Specifications (Standard Condition: 25℃, Vin=5V, Vout=1.8V, Full Load)

Input Voltage Range: 4.5V – 8V (Typical 5V)Adjustable Output Voltage: 0.7V – 1.8V (Set by external resistor)Max Continuous Output Current: 20AMax Output Power: 36WTypical Switching Frequency: 500kHzMax Efficiency: 93.2% (Approx. 89% at 1.8V/20A)

Output Voltage AccuracyLine Regulation: ±1.0%Load Regulation: ±1.0%Temperature Drift: ±1.5% (-40℃ ~ +105℃)Output Ripple & Noise: ≤ 80mV (20MHz Bandwidth)Quiescent Current: Approx. 1mA

Protection Functions: Over current, over voltage, over temperature, short circuit and under voltage lockout (UVLO)Control Interfaces: Positive logic ON/OFF enable, Power Good signal, remote sense

Mechanical & Environmental Specifications

Package Dimension: 10.5 × 9.0 × 5.6mm (SMD Module)Pin Type: 37-pin LGAOperating Temperature: -40℃ ~ +105℃ (Industrial Grade)Packaging: Tape & Reel, suitable for SMT mass productionWeight: About 2.2g
