TPD6F002DSVR (TI Texas Instruments, 6-Channel EMI Filter and ESD Protection Array)

Dual-function device: Integrates RC Pi-type low-pass EMI filter and TVS ESD protection. It is placed at the entrance of high-speed signal lines to suppress electromagnetic interference (EMI) on signal lines and dissipate electrostatic discharge (ESD). It protects downstream ICs such as main controllers, LCD panels, FPGAs and sensors from ESD damage and reduces signal radiated interference.

Widely adopted by many PCB and solution customers for display cables, FPD-Link and GPIO interfaces.

Core Features

6-channel RC Pi-type low-pass filter (R=100Ω, C=34pF per channel) to suppress high-frequency electromagnetic noise and reduce EMI radiation and crosstalk.

Integrated ESD TVS protection diode array, compliant with IEC61000-4-2 Level4 ESD standard

±20kV contact discharge

±30kV air discharge

Bandwidth: 100MHz at -3dB, preserves valid signals below 100MHz

Ultra-low leakage current: maximum 20nA, suitable for low-power devices

Maximum operating voltage: 5.5V, unidirectional signal protection

WSON12 package, compact size for dense PCB layout

Key Specifications

Brand: Texas Instruments (TI)

Package: WSON-12, dimension 3.0 × 1.35 × 0.8 mm

Channels: 6 channels

Filter topology: Pi-type C-R-C, R=100Ω, total capacitance 34pF

Rated signal voltage: 5.5V

Operating temperature: -40℃ ~ +85℃ (consumer / industrial general purpose, non-automotive; automotive version: TPD6F002-Q1)

ESD protection: ±20kV (contact) / ±30kV (air), IEC61000-4-2 Level4

-3dB bandwidth: 100MHz

Leakage current: max. 20nA @3.3V

Applications

LCD display interfaces, FPD-Link, LVDS display cables

Memory interfaces, SIM cards, general-purpose GPIO signal lines

Signal lines with flexible flat cables (FPC cables are prone to ESD and EMI interference)

Industrial IoT, handheld devices, meters, robot control boards
