CGA1A1X7S1E104K030BCTDK Automotive Grade Multilayer Ceramic Chip Capacitor

Ⅰ. Core Parameters (Model Decoding)

Series: CGA = Automotive grade (AEC‑Q200), low ESL, soft termination electrodeSize: 1 = 0603(0201), dimension: 0.6×0.3×0.3mmThickness: A = 0.3mmDielectric: X7S = Temperature characteristic ±22% (-55℃～+125℃)Rated Voltage: 1E = 25V DCCapacitance: 104 = 100nF (0.1μF)Tolerance: K = ±10%Terminal Electrode: BC = Soft termination (thermal shock resistance & bending crack resistance)

Ⅱ. Core Functions

Power decoupling & filtering: Suppress power noise, stabilize voltage, reduce ESR/ESL with excellent high-frequency noise reduction performance.EMC solution: Wideband noise reduction, reduce EMI interference and improve system anti-interference capability.Voltage smoothing & regulation: Smooth voltage and reduce ripple in power circuits such as automotive ECU and BMS.Coupling & DC blocking: Block DC and pass AC in signal circuits to protect post-stage circuits.

Ⅲ. Application Scope

✅ Automotive Electronics (Main Application)

Powertrain domain: Engine ECU, BMS, OBC, DC-DCChassis & safety system: ABS, ESP, ADAS, autonomous driving domain controllerBody & cockpit: Instrument panel, central control, BCM, vehicle lamps, car navigation, T-Box

✅ Industrial & High-end Consumer Electronics

Industrial control: PLC, servo drive, sensors, industrial power supplyHigh-end equipment: Medical devices, communication base stations, security equipment, smart home control boardsHigh-reliability scenarios: Equipment requiring vibration resistance, wide temperature resistance (-55℃～+125℃) and low stress cracking resistance

Ⅳ. Key Advantages

Automotive certification: Compliant with AEC‑Q200 automotive reliability standardsLow ESL / Low ESR: Inverse geometry structure with low impedance and high decoupling efficiencySoft termination: Resin buffer layer relieves stress, preventing cracks caused by PCB bending and thermal shockExcellent temperature stability: X7S dielectric, capacitance variation ≤ ±22% within -55℃～+125℃
